MGN-C/MGN-H series

slide linear guide rail block MGN15C

Details of MGN15C

Product name:slide linear guide rail block MGN15C

Series:MGN

Size:15

Block No:MGN15C, MGN15CZFC, MGN15CZ0C, MGN15CZ0H, MGN15CZ1C, MGN15CZ1H

Block Type: Standard

Block preload:Light Clearance(ZF), Very Light Preload(Z0),  Light Preload (Z1)

Precision code/Accuracy Classes: C,H

Class Code Preload Accuracy
Light Clearance ZF Clearance 4~10μm C
Very light preload Z0 0 C-P
Light preload Z1 0.02C C-P

Datasheet of MGN15C

.



H Total height 16 mm
H1   4 mm
H1 With bottom seal 3 mm
N   8.5 mm
W Block width 32 mm
B   25 mm
B1   3.5 mm
C   20
L1   26.7 mm
L Block length 42.1 mm
Gn   M3
M   M3 mm
l   4 mm
H2   3 mm
  Mass 0.06 kg
